A un vistazo
Provides HDMI (adaptable to DVI-D) and BNC output interfaces
Up to 4K (3840 × 2160@30Hz) via HDMI output interfaces (only for odd interface)
Up to 8-ch decoding at 24 MP resolution
H.265+/H.265, H.264+/H.264, Hik264, MPEG4 and MJPEG video compression
PS, RTP, TS, ES, HIK encapsulation formats
Three encoding levels: baseline, main, and high-profile
G.722, G711A, G726, G711U, MPEG2-L2, and AAC audio compression
Two decoding modes: active decoding and passive decoding
Supports two-way audio via client software
Remote video files' decoding output
Provides VGA and DVI input interfaces
Supports window opening, window roaming and window split
Supports multi-screen control with PC installed with RSC server
Gets stream and decodes via URL and RTSP from encoding devices
Displays the decoded video stream on the video wall by directly linking cameras or by stream media forwarding
Detalles del producto
(1) preguntas y (0) respuestas sobre este producto
¿No encuentras la respuesta a tu duda?
Especificaciones
Puertos e Interfaces | |
---|---|
Ethernet LAN (RJ-45) cantidad de puertos | 2 |
Tipo de conector de audio | 3.5 mm (1/8 ") |
Number of HDMI outputs | 16 |
Puertos RS-485 | 1 |
Puerto - RS-232 | 1 |
puertos de salida BNC | 8 |
Peso y dimensiones | |
---|---|
Ancho del paquete | 566 mm |
Altura | 88 mm |
Largo del paquete | 222 mm |
Alto del paquete | 620 mm |
Profundidad | 321 mm |
Ancho | 440 mm |
Detalles técnicos | |
---|---|
Color del producto | Negro |
Control de energía | |
---|---|
Potencia de adaptador AC | 108 W |
Voltaje de entrada de adaptador AC | 100 - 240 V |
Conexión | |
---|---|
Ethernet LAN, velocidad de transferencia de datos | 10,100,1000 Mbit/s |
Tipo de interfaz ethernet | Gigabit Ethernet |
Tecnología de cableado | 10/100/1000BaseE-T(X) |
