A un vistazo
Physical Port
8 10/100/1000BASE-T Gigabit RJ45 copper ports
2 100/1000BASE-X mini-GBIC/SFP ports
RJ45 console interface for switch basic management and setup
Layer 2 Features
Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth
Supports VLAN
IEEE 802.1Q tagged VLAN
Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
Protocol VLAN
Voice VLAN
Private VLAN (Protected port)
Management VLAN
GVRP
Supports Spanning Tree Protocol
STP (Spanning Tree Protocol)
RSTP (Rapid Spanning Tree Protocol)
MSTP (Multiple Spanning Tree Protocol)
STP BPDU Guard, BPDU Filtering and BPDU Forwarding
Supports Link Aggregation
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
Cisco ether-channel (static trunk)
Maximum 1 trunk group, up to 2 ports per trunk group
Provides port mirror (many-to-1)
Loop protection to avoid broadcast loops
Supports ERPS (Ethernet Ring Protection Switching)
Quality of Service
Ingress/Egress Rate Limit per port bandwidth control
Storm Control support
Broadcast/Unknown-Unicast/Unknown-Multicast
Traffic classification
IEEE 802.1p CoS
TOS/DSCP/IP Precedence of IPv4/IPv6 packets
Strict priority and Weighted Round Robin (WRR) CoS policies
Multicast
Supports IPv4 IGMP snooping v2 and v3
Supports IPv6 MLD snooping v1, v2
IGMP querier mode support
IGMP snooping port filtering
MLD snooping port filtering
Security
Authentication
IEEE 802.1X Port-based network access authentication
Built-in RADIUS client to co-operate with the RADIUS servers
RADIUS/TACACS+ login user access authentication
Access Control List
IPv4/IPv6 IP-based ACL/ACE
MAC-based ACL/ACE
MAC Security
Static MAC
MAC Filtering
Port Security for Source MAC address entries filtering
DHCP Snooping to filter distrusted DHCP messages
Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
IP Source Guard prevents IP spoofing attacks
DoS Attack Prevention
Management
IPv4 and IPv6 dual stack management
Switch Management Interface
Web switch management
Console/Telnet Command Line Interface
SNMP v1 and v2c switch management
SSHv2, TLSv1.2 and SNMP v3 secure access
User Privilege Levels Control
Built-in Trivial File Transfer Protocol (TFTP) client
BOOTP and DHCP for IP address assignment
System Maintenance
Firmware upload/download via HTTP/TFTP
Configuration upload/download via HTTP/TFTP
Dual Images
Hardware reset button for system reboot or reset to factory default
SNTP Network Time Protocol
Cable Diagnostics
Link Layer Discovery Protocol (LLDP) Protocol and LLDP-MED
SNMP trap for interface Link Up and Link Down notification
Event message logging to remote Syslog server
Four RMON groups (history, statistics, alarms, and events)
PLANET NMS System and Smart Discovery Utility for deployment management
Detalles del producto
Preguntas y respuestas sobre este producto
Aún no hay preguntas acerca de este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
| Puertos e Interfaces | |
|---|---|
| Cantidad de puertos básicos de conmutación RJ-45 Ethernet | 8 |
| Número de módulos SFP instalados | 2 |
| Puertos tipo básico de conmutación RJ-45 Ethernet | Gigabit Ethernet (10/100/1000) |
| Peso y dimensiones | |
|---|---|
| Altura | 44 mm |
| Profundidad | 180 mm |
| Ancho | 280 mm |
| Control de energía | |
|---|---|
| Consumo energético | 6.8 W |
| Fuente de alimentación incluida |
|
| Frecuencia de entrada AC | 50/60 Hz |
| Corriente de entrada | 2.5 A |
| Voltaje de entrada AC | 100 - 240 V |
| Diseño | |
|---|---|
| Material de la carcasa | Metal |
| Certificación | FCC Part 15 Class A, CE |
| Montaje en rack |
|
| Color del producto | Azul |
| Factor de forma | 1U |
| Indicadores LED |
|
| Transmisión de datos | |
|---|---|
| Capacidad de conmutación | 20 Gbit/s |
| Jumbo Frames, soporte |
|
| Guardar y remitir |
|
| Tabla de direcciones MAC | 8000 entradas |
| Número de VLANs | 256 |
| Tramas Jumbo | 10000 |
| Rendimiento | 14.88 Mpps |
