A un vistazo
All doors have toolless hinges that allow the doors to easily be removed or reversed in the field
All doors have ergonomic opening, keylocking handles
Easy-to-remove side panels with keylocking latch
Front and rear doors are fully perforated to allow for maximum air flow
Top accepts additional cooling fans (2 x 6-in. fans) with integral finger guard prefabricated in place
Top has sliding gland plate to accommodate large cable egress capacity
Combination foot and adjustable leveler in each cabinet corner
Open base for easy cable entrance
Rack angles are fully adjustable front to rear, easily converting between tapped or square configurations
Rack angles able to mount off-centered on 700 and 800mm wide models
Rack angles able to configure at 23” spacing on 700 and 800mm wide models
Perforated doors meet or exceed manufactures open space/air flow ventilation requirements
Detalles del producto
Preguntas y respuestas sobre este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
Peso y dimensiones | |
---|---|
Altura | 2163 mm |
Profundidad | 898 mm |
Peso | 147.3 kg |
Ancho | 808 mm |
Detalles técnicos | |
---|---|
Código IP (International Protection) | IP20 |
Número de ventiladores | 2 |
Diseño | |
---|---|
Tipo | Rack o bastidor independiente |
Color del producto | Negro |
Materiales | Acero |
Características | |
---|---|
Paneles laterales desmontables | |
Side panel key lock | |
Back door key lock | |
Estructura de la puerta delantera | Perforado |
Back door construction | Steel/Perforated |
Grosor de los carriles del bastidor | 1.52 mm |
Tipo de enfriamiento | Activo |
Diámetro de ventilador | 15.2 cm |
Side panel construction | Acero |
Puerta delantera con cerradura | |
Bloqueo del teclado | |
Capacidad del rack | 45U |
