La licencia es aplicable a los siguientes productos:
A un vistazo
Physical Ports
8 10/100/1000Mbps Gigabit Ethernet ports with auto-MDI/MDI-X supported
1 port (Port 8) supports 802.3af/at PoE 48~56V DC in-line power
2 100/1000Base-X mini-GBIC/SFP slots
Installation
Dual Power Design
802.3af/at PoE In- 12V DC power adapter acceptable
Layer 2 Features
Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth
Supports VLAN
IEEE 802.1Q tagged VLAN- Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)- Protocol VLAN- Voice VLAN- Private VLAN- Management VLAN- GVRP
Supports Spanning Tree Protocol
STP (Spanning Tree Protocol)- RSTP (Rapid Spanning Tree Protocol)- MSTP (Multiple Spanning Tree Protocol)- STP BPDU Guard, BPDU Filtering and BPDU Forwarding
Supports Link Aggregation
IEEE 802.3ad Link Aggregation Control Protocol (LACP)- Cisco ether-channel (Static Trunk)- Maximum 8 trunk groups, up to 8 ports per trunk group
Provides Port Mirror (many-to-1)
Loop protection to avoid broadcast loops
Quality of Service
Ingress / Egress Rate Limit per port bandwidth control
Storm Control support
Broadcast / Unknown-Unicast / Unknown-Multicast
Traffic classification
IEEE 802.1p CoS- TOS / DSCP / IP Precedence of IPv4/IPv6 packets
Strict priority and Weighted Round Robin (WRR) CoS policies
Multicast
Supports IGMP Snooping v1, v2 and v3
Supports MLD Snooping v1 and v2
IGMP Querier mode support
IGMP Snooping port filtering
MLD Snooping port filtering
Security
Authentication
IEEE 802.1X Port-based network access authentication- Built-in RADIUS client to co-operate with the RADIUS servers- RADIUS / TACACS+ login user access authentication
Access Control List
IPv4 / IPv6 IP-based ACLMAC-based ACL
MAC Security
Static MAC- MAC Filtering
Port Security for Source MAC address entries filtering
DHCP Snooping to filter distrusted DHCP messages
Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
IP Source Guard prevents IP spoofing attacks
DoS Attack Prevention
SSH / SSL
Management
IPv4 and IPv6 dual stack management
Switch Management Interface
Web switch management- Telnet Command Line Interface- SNMP v1, v2c and v3- SSH / SSL secure access
User Privilege Levels Control
Built-in Trivial File Transfer Protocol (TFTP) client
BOOTP and DHCP for IP address assignment
System Maintenance
Firmware upload/download via HTTP / TFTP- Configuration upload / download through Web interface- Hardware reset button for system reboot or reset to factory default
SNTP Network Time Protocol
Cable Diagnostics
Link Layer Discovery Protocol (LLDP) Protocol and LLDP-MED
SNMP trap for interface Link Up and Link Down notification
Event message logging to remote Syslog server
Four RMON groups (history, statistics, alarms, and events)
PLANET Smart Discovery Utility
Detalles del producto
Preguntas y respuestas sobre este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
Puertos e Interfaces | |
---|---|
Cantidad de puertos básicos de conmutación RJ-45 Ethernet | 8 |
Número de módulos SFP instalados | 2 |
Puertos tipo básico de conmutación RJ-45 Ethernet | Gigabit Ethernet (10/100/1000) |
Peso y dimensiones | |
---|---|
Altura | 2,6 cm |
Profundidad | 8,6 cm |
Peso | 396 g |
Ancho | 19,1 cm |
Otras características | |
---|---|
Voltaje de entrada | 12 |
Control de energía | |
---|---|
Consumo energético | 10,9 W |
Fuente de alimentación incluida | |
Número de fuentes de alimentación | 1 |
Diseño | |
---|---|
Certificación | FCC Part 15 Class A, CE |
Color del producto | Negro |
Indicadores LED | Actividad, Enlace, Poder |
