A un vistazo
Physical Port
8-port 10/100/1000BASE-T Gigabit RJ45 copper
2 10/100/1000BASE-T TP interfaces and 2 1000BASE-X mini-GBIC SFP shared combo interfaces
Power over Ethernet
Complies with IEEE 802.3af/at Power over Ethernet end-span PSE
Up to 8 ports of IEEE 802.3af/802.3at devices powered
Supports PoE power up to 32 watts for each PoE port
Each port supports 52V DC power to PoE powered device
120-watt PoE budget
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m in standard mode and 250m in extend mode
Smart LCD
The LCD switch features “Standard”, “VLAN” and “Extend” mode selection; the “Extend” mode features 30-watt PoE transmit distance of 250m at speed of 10Mbps and VLAN isolation
The LCD switch is able to isolate ports to prevent broadcast storm and defend DHCP spoofing
Power low-voltage, power over-voltage and PSE over-temperature protection
Screen saver, fan control, factory default and save configuration
PoE management
Total PoE power budget control
Per port PoE function enable/disable
PoE port power feeding priority
Per PoE port power limitation
PD alive check
Switching
Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
Flow control for full duplex operation and back pressure for half duplex operation
9216bytes packet size
Integrates address look-up engine, supporting 8K absolute MAC addresses
IEEE 802.1Q VLAN transparency
Automatic address learning and address aging
Hardware
12-inch desktop size, 1U height, rack mountable
2-inch color LCD with smart management functions
LED indicators for system power, per port PoE ready and PoE activity, speed, Link/Act
1 silent fan to provide stable and efficient power performance
Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
Supports contact discharge of ±4KV DC and air discharge of ±6KV DC for Ethernet ESD protection
Supports ±4KV surge immunity
Detalles del producto
Preguntas y respuestas sobre este producto
Aún no hay preguntas acerca de este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
| Puertos e Interfaces | |
|---|---|
| Cantidad de puertos básicos de conmutación RJ-45 Ethernet | 8 |
| Puertos tipo básico de conmutación RJ-45 Ethernet | Fast Ethernet (10/100) |
| Combo SFP Cantidad de puertos | 2 |
| Peso y dimensiones | |
|---|---|
| Altura | 44 mm |
| Profundidad | 280 mm |
| Peso | 1,8 kg |
| Ancho | 180 mm |
| Control de energía | |
|---|---|
| Consumo de energía (max) | 130 W |
| Frecuencia de entrada AC | 50/60 |
| Corriente de entrada | 2.5 |
| Voltaje de entrada AC | 100-240 |
| Diseño | |
|---|---|
| Material de la carcasa | Metal |
| Certificación | FCC, CE |
| Montaje en rack |
|
| Color del producto | Negro |
| Número de ventiladores | 1 |
| Factor de forma | 1U |
| Indicadores LED |
|
| Transmisión de datos | |
|---|---|
| Capacidad de conmutación | 5,6 Gbit/s |
| Guardar y remitir |
|
| Tabla de direcciones MAC | 4096 entradas |
