A un vistazo
Serial Interface
One DB9 interface supports RS232, 2-wire RS485, 4-wire RS485 and RS422 operation
Asynchronous serial data rates up to 921600bps
Data mode includes VCOM, RFC2217, TCP Server, TCP Client, UDP, Remote Pair, Modbus converter server / client and Serial Telnet modes
Ethernet Interface
1-port 10/100BASE-TX RJ45 interface with auto MDI/MDI-X function
Management
IPv4 and IPv6 dual stack management
Remote Management Interfaces
IP-based Web management
Telnet console management
Windows-based VCOM utility supports searching, monitoring and configuration setting
IP NTP (Network Time Protocol)
Standard TCP/IP interface and versatile operation modes
Software Protocol supports ICMP, TCP/IP, UDP, HTTP server, DHCP client, Telnet server/client
Serial Operation mode selected via management interface
Pair Connection mode for connecting two serial devices over a network
Allows a maximum of 4 hosts to be accessed as TCP client mode
Firmware upgrade via HTTP protocol
Accessible IP security control to prevent illegal users
Event notification
Remote syslog server
SNMP trap
DHCP client for IP address assignment
PLANET Smart Discovery utility automatically finds the client devices on the netw
Case and Installation
Compact size for easy Installation
Standalone -- Wall mountable or DIN-rail mounting (optional accessory)
Co-works with PLANET MC family Media Chassis (MC-700/1500)
External power adaptor 5V DC, 2A max
Supports 6000 VDC Ethernet ESD protection
10 to 60 degrees C operating temperature
Supports extensive LED indicators for network diagnosis
Reset button for resetting to factory default
Detalles del producto
Preguntas y respuestas sobre este producto
Aún no hay preguntas acerca de este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
| Puertos e Interfaces | |
|---|---|
| Ethernet LAN (RJ-45) cantidad de puertos | 1 |
| Peso y dimensiones | |
|---|---|
| Peso | 184 g |
| Detalles técnicos | |
|---|---|
| Bits de datos | 5,6,7,8 |
| Tipo de control de flujo | DTR/DSR,RTS/CTS,XON/XOFF |
| Puerto serial | 1 |
| Bits de parada | 1,1.5,2 |
| Otras características | |
|---|---|
| Dimensiones (Ancho x Profundidad x Altura) | 97 x 70 x 26 mm |
| Diseño | |
|---|---|
| Certificación | FCC Part 15 Class A, CE Certification Class A |
| Color del producto | Negro |
| Indicadores LED | Sistema |
