La licencia es aplicable a los siguientes productos:
A un vistazo
Complies with IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, IEEE 802.3z 1000BASE-SX/LX
TP port supports 10/100/1000BASE-T auto-negotiation and auto-MDI/MDI-X
1000BASE-SX: 50/125μm or 62.5/125μm multi-mode fiber cable, up to 220/550m (GT-802)
1000BASE-LX: 9/125μm single-mode cable provides a distance of 10km (GT-802S)
1000BASE-LX: 9/125μm single-mode cable provides a distance of 40km (GT-802S40)
1000BASE-LX: 9/125μm single-mode cable provides a distance of 60km (GT-802S60)
1000BASE-SX/LX: 50/125μm/62.5/125μm multi-mode fiber cable or 9/125μm single-mode cable provides a distance depending on SFP module (GT-805A)
1000BASE-LX WDM interface is for up to 15km (single-mode fiber 9μm/125μm) on GT-806A15/GT-806B15
1000BASE-LX WDM interface is for up to 40km (single-mode fiber 9μm/125μm) on GT-806A40/GT-806B40
1000BASE-LX WDM interface is for up to 60km (single-mode fiber 9μm/125μm) on GT-806A60/GT-806B60
1000BASE-T: 2-pair Cat. 5/5e/6 UTP cable, up to 100 meters
Layer 2 key features
IEEE 802.3x flow control for full duplex and back pressure for half duplex eliminate the loss of packets
Supports auto MDI/MDI-X function
Store-and-Forward mechanism
Non-blocking full wire-speed forwarding rate
Media conversion between 10/100/1000BASE-T and 1000BASE-SX/LX
Fiber media allows
Multi-mode fiber using SC/LC/WDM connector
Single-mode fiber using SC/LC/WDM connector
Compact size for working with PLANET MC family media chassis (MC-700/MC-1500/MC-1500R/MC-1500R48)
Wall-mountable design
LED indicators for easy network diagnostics
Provides DIP switch for LFP function (Disable/Enable) setting
9K jumbo frame supported
Choice of fiber connectors from SC, LC and WDM; multi-mode/single-mode fiber for 1000BASE SFP interface
Compact in size, easy installation
Detalles del producto
Preguntas y respuestas sobre este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
Puertos e Interfaces | |
---|---|
Tecnología de conectividad | Alámbrico |
Ethernet LAN (RJ-45) cantidad de puertos | 2 |
Conector fibra óptica | SC |
Puertos de canal de fibra | 1 |
Peso y dimensiones | |
---|---|
Altura | 26 mm |
Profundidad | 70 mm |
Peso | 200 g |
Ancho | 94 mm |
Control de energía | |
---|---|
Voltaje de entrada | 5 |
Consumo energético | 5,6 W |
Corriente de entrada | 2 |
Diseño | |
---|---|
Certificación | FCC Class A, CE Class A |
Color del producto | Negro |
Interno | |
Indicadores LED |
Conexión | |
---|---|
Estándares de red | IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3z |
Tasa de transferencia (máx) | 1000 Mbit/s |
Ethernet LAN, velocidad de transferencia de datos | 10,100,1000 Mbit/s |
Tipo de interfaz ethernet | Gigabit Ethernet |
Interfaz de convertidor de salida | 1000Base-LX |
Sistema de dúplex | Completo, Semi (dúplex) |
Interfaz de convertidor de entrada | 10Base-T |
Auto MDI / MDI-X |
