Standard
keyboard_arrow_right
Complies with IEEE 802.3 10BASE-T
keyboard_arrow_right
Complies with IEEE 802.3u 100BASE-TX/100BASE-FX
keyboard_arrow_right
Complies with IEEE 802.3ab 1000BASE-T
keyboard_arrow_right
Complies with IEEE 802.3z 1000BASE-SX/LX
keyboard_arrow_right
IEEE 802.3x full-duplex flow-control, back-pressure in half-duplex eliminate packets loss
keyboard_arrow_right
Interface
keyboard_arrow_right
Dual 100BASE-FX/1000BASE-SX/LX SFP fiber-optic slots
keyboard_arrow_right
One 10/100/1000BASE-T Copper, auto MDI/MDIX function
keyboard_arrow_right
Auto-negotiation for 10/100/1000BASE-T; half-duplex or full-duplex for 10Mbps and 100Mbps, full-duplex for 1000Mbps
keyboard_arrow_right
Supports maximum frame size up to 10K jumbo packet size
keyboard_arrow_right
IEEE 802.1Q Tag VLAN transparent, multicast pass through
keyboard_arrow_right
Redundancy
keyboard_arrow_right
Link status auto-detecting and redundant on dual ports with the same connector type
keyboard_arrow_right
Allows only the Primary-Port or the Backup-Port to activate at a time
keyboard_arrow_right
When the Primary-Port link fails occurs, the traffic swaps to Backup-Port automatically
keyboard_arrow_right
Once the Primary-Port link regains, the traffic swaps from the Backup-Port to the Primary-Port
keyboard_arrow_right
Hardware fiber port redundant
keyboard_arrow_right
Mechanical
keyboard_arrow_right
External 5V/2.5A DC power supply
keyboard_arrow_right
LED indicators for easy network diagnose
keyboard_arrow_right
DIP switch for 100FX or 1000X SFP module supports on dual SFP slots
keyboard_arrow_right
DIP switch for 3-port operation in Gigabit switch mode or redundant mode
keyboard_arrow_right
Compact in size, easy installation
keyboard_arrow_right
Co-works with PLANET 10”/19” Media Converter Chassis (MC-700/MC-1500/MC-1500R/MC-1500R48)
keyboard_arrow_right
Wall mounting and DIN-Rail installation supported
