A un vistazo
Interface
1-port 10/100Base-T RJ-45 with auto negotiation and auto-MDI/MDI-X function
1 100Base-FX SC interface, providing long distance up to 2km on IFT-802T
1 100Base-FX SC interface, providing long distance for 15km on IFT-802TS15
1 Mini-GBIC slot, providing multi choice of SFP modules on IFT-805AT
Industrial Conformance
12V to 48V DC, redundant power with polarity reverse protect function
Minus 40 to 75 degrees C operating temperature
IP30 metal case
Relay alarm for port breakdown
Supports 6KV DC Ethernet ESD protection
Supports 6KV DC EFT protection for power line
Free Fall, Shock and Vibration Stability
DIN-rail and wall-mountable hardware design
Layer 2 Features
Complies with the IEEE 802.3, IEEE 802.3u Fast Ethernet standard
Auto-MDI / MDI-X detection and auto negotiation in half-duplex / full-duplex modes for 10 /100Base-TX RJ-45 port
Store-and-Forward Switching Architecture
Features Store-and-Forward mode with wire-speed filtering and forwarding rates
Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
Supports packet size of up to 1522bytes
CSMA/CD Protocol
Automatic source address learning and aging
Detalles del producto
Preguntas y respuestas sobre este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
Puertos e Interfaces | |
---|---|
Tecnología de conectividad | Alámbrico |
Ethernet LAN (RJ-45) cantidad de puertos | 1 |
Peso y dimensiones | |
---|---|
Altura | 32 mm |
Profundidad | 85 mm |
Peso | 430 g |
Ancho | 135 mm |
Detalles técnicos | |
---|---|
Sustainability certificates | RoHS |
Control de energía | |
---|---|
Consumo energético | 3 W |
Diseño | |
---|---|
Montaje en carril DIN | |
Código IP (International Protection) | IP30 |
Certificación | FCC, CE |
Color del producto | Negro |
Interno | |
Indicadores LED |
